DÂY CÁP TÍN HIỆU CC-LINK CHUYỂN ĐỘNG KURAMO FANC-110SBZ-5 3C x 0.5㎟ 75℃ VW-1 FT1 Dark Brown | Chính Hãng – Moving Cable – Giá Tốt Nhất

Hãng Sản Xuất: KURAMO ELECTRIC

Xuất Xứ: MADE IN JAPAN

Dây cáp tín hiệu truyền thông CC-LINK chuyển động (Moving cable) KURAMO FANC-110SBZ-5 được sử dụng Dây dẫn bằng đồng ủ, Size 0.5㎟ × 3C, Cách điện: PE màu Blue, White, Yellow, Chống nhiễu: Tin coated annealed copper braid , Vỏ ngoài: Loại thảm PVC chịu dầu và chịu nhiệt, Màu vỏ: Nâu đậm.

Product Description

For Quotation, please click the Contact Us button below.

(1coil/100m≒328ft) Basically 100m MOQ,

Cutting under 100m or Made to order should be confirm with us.

The FANC-110SBH Series are FA network cables designed to comply with CC-Link Ver.1.10. The FANC-110SBH Series, when used to network CC-Link Ver.1.10 compliant equipment, allows the formation of a network subject to less restriction in cable connection than the FANC-SB Series (CC-Link Ver.1.00 compliant). FANC110SBH as standard of this series and its power pair built-in composite type, PW110BH, are certified to comply with the UL/cUL AWM requirements.

Use

■ Wiring between the equipment and equipment which adapted to CC-Link Ver. 1.10.

Certification

cRUus – EAC

Features

■ Double shield, 10Mbps transmission, RS-485 compliance
■ Availability in a large variety of types to meet various application requirements
※For details, refer to each cable’s Specifications given below.
■The movable type FANC-110SBZ-5 cable is designed so that its transmittable distance is 50% that of its standard counterpart.
※The use of the cable at high ambient temperature may cause its transmittable distance to be shortened.
※ The PW110SBH’s power pair (0.75㎟ ) is required to be used at a voltage less than 100V in such applications as DC24V power supply for remote I/O.

Specifications

Technical data

■ (20℃）Conductor resistance: 43.4 Ω /㎞

■ (5MHz）Characteristic impedance: 110 Ω

■ (5MHz, 20℃）Attenuation: 6.1dB/100m

■ Temperature rating: 75℃

■ Application: Movable wiring

■ Sheath diameter: Approx. 8.0㎜

■ Approx. weight: 70 kg/㎞

Construction

Size 0.5㎟ × 3C

Insulation: PE

Insulation color: Blue, White, Yellow

Shield: Tin coated annealed copper braid

Sheath: Oil and heat resistant PVC mat type

Sheath color: Dark Brown
